So is the take home message that 2.7K is more like native resolution and will usually give best quality?
Must say this chimes with experience of smaller digital cameras which often seemed to look best one down from 'best' quality recording.
May well try it anyway as 4K seems overkill for youtube.
Also I can stream 1440p with minimal buffering - but 4K is still impossible even over the router from main PC upstairs.
The
native resolution of the camera sensor which is fitted to both the Pro and the Advanced is definitely 4k.
So in principle (if the camera optics are good enough!) 4k should be the ultimate quality output. Many owners and potential buyers take that for granted.
However as has been well discussed on this forum, the video processing electronics are a serious bottleneck. The tiny circuit inside the gimbal base is being seriously challenged by the 4k stream, even when asked to tackle 60 Million bits per second. Hence the bolt-on fan. 60Mbps is a very low data rate for 4k. If you think that one single uncompressed frame of 4096x2160 = 9 Million pixels, its clear that a lot of image detail is being lost. Another way of looking at it is that the most recent optical media; Bluray, uses 40Mbps to deliver a video image that is only 1/4 the size of 4k. So for the Phantom to deliver a similar
quality per pixel as Bluray it would have to process and deliver 160Mbps, not 60Mbps.
Since it was a wet and windy day in England today I stayed home, recorded and measured all of the available video bitrates of the P3A and P3P. (Actually I did skip over the strange 48 fps formats)
The results are in the table below, and include some surprises.
The colour codes are courtesy of Excel 2013 Conditional Formatting Colour Scale; Green is the best and Red the worst.
Just looking at the first two coloured columns first, the 60Mbps ceiling of the 4k circuitry is well known.
Although it is there in the DJI documentation I had not realised until today that it cannot manage 30fps at true
4k (4096x2160).
But it can manage the lower resolution variant that most salesmen are now calling 4k;
UHD (3840x2160).
Of course there are no results for the P3A for either of those resolutions because its video circuit is not able to handle them.
Moving on down to
2.7k, it has been claimed that the ceiling of the P3A circuit is 40Mbps.
But from my measurements using both MediaInfo and Bitrate Viewer, this circuit definitely delivers all three available frame rates at 45Mbps. Exactly the same as the P3P.
In fact for every video format that the P3A and P3P have in common, they use the same bitrate.
But
('Full') HD is the real surprise. Someone needs to double check this. I repeatedly found that the
P3A circuit delivers 60Mbps with the 1080p60 video format.
In contrast the European PAL equivalent (1080p50) complies with the reported 40Mbps ceiling.
Do we need 60Mbps for FHD anyway? I argue yes.
As a reference, Bluray has a ceiling of
40Mbps to deliver FHD at 60i (2 half frames of 60 fps, which is basically the same demand as 1 full frame of 30fps).
So we can say that both the P3A and P3P process FHD 30fps video data quickly enough to be able to deliver something equivalent to Bluray quality.
If Bluray was asked to deliver FHD at 60p (fullframes, not half frames) it would need 80Mbps. So the 60Mbps that the P3A uses at 60p is not at all extravagant.
I don't know if anyone is interested in capturing at
1280x720 (720p) these days. But even if the video processor could provide a very impressive bits/pixel at this low resolution, it doesn't. The quality per pixel is almost as poor as the 4k and UHD resolutions.
Then just for interest, at the bottom of the table I've put the Live video bitrates streamed to the controller. Both P3A and P3P use
720P for that.
The P3A is locked at a bit more than the 2Mbps spec declared by DJI. And in contrast, although they claim that the P3P can stream at 10Mbps I've not seen it exceed 6.5Mbps.
P3P does have a higher frame rate though (30fps vs 25fps).
MediaInfo also reports the bits/pixel quality of the video. So the right two columns give that info. It is interesting to note that the bitrate per pixel of P3P UHD at 30fps is the same as the live feed!
I am not saying that the image quality of both is the same of course. The recorded UHD image is 3 x 720p resolution in both width and height. But the amount of data available to describe each pixel is the same. If you took a 1280x720 chunk out of the UHD video and compared it to a close live feed it would probably look similar in terms of processing artifacts...in fact I might try that...
Above I raised the comparison with Bluray. We can see from the Green (0.64 bits per pixel) bar in the table at FHD 30p that this is the highest bitrate/pixel that both P3A and P3P deliver.
So 4wd, this post is an awfully long way of saying that
the 'sweet spot' of both P3A and P3P is actually just 1080p30, not even 2.7k. No doubt when DJI have a P4 Pro ready to roll they will be able to truthfully tell us that they do really have Professional Quality 4k video recording!
It probably sounds like I am knocking DJI. In reality I think the Phantom 3 is an absolute marvel, ahead of the curve. I love it. But we shouldn't fool ourselves. Just because the wizards have somehow managed to squeeze some form of 4k recording into its tiny frame and price doesn't mean that this is already the ultimate in 4k video quality.
Just as a reality check, look up to the awesome Zenmuse X5R camera that DJI have just launched and puzzle at how that Pro 4k monster could be hung on a Phantom. But technology has a knack of shrinking in size and cost with time.
I've still got my first 1991 Sony tape 'palmcorder' as a reminder of how technology and our quality standards advance.
Enough already.....
